Tag Archives: Field Day

Sights From Field Day 2017

Field Day 2017 is but a memory for us now. Dave, K1DLM, our Field Day Chairman, and the entire Field Day team did a great job with putting together our Field Day operation this year.

We are still adding up our score and collecting pictures and video from everyone. I wanted to get something out quickly so that we could begin to enjoy some of the memories. So here is my quick Sights from Field Day 2017….

Field Day 2017 Telegraph Article
Our Field Day Telegraph Article

We did a fantastic job on publicity this year…

Field Day 2017 - Parking Lot Was Full
The Parking Lot Was Full

and the parking lot was full of visitors and members on Saturday and Sunday.

Field Day 2017 Public Info Tent Was A Hit
Our Public Info Tent Is A Hit

Our updated Public Information Tent was a hot spot for our many visitors (over 45 visitors signed our guest register)!

Field day 2017 Visitors - ARRL Section Leaders - Peter, K1PJS And John, K1UAF
ARRL Section Leaders – Peter, K1PJS And John, K1UAF

The ARRL “brass” came out early to congratulate Dave, K1DLM our Field Day Chairman, and to tour our site.

Field day 2017 Food Was Awesome!
The Food Was Awesome!

The food was unbelievably good – thanks, Valerie!!! And the N1FD cafe’ was a hot-spot as usual.

Field Day 2017 Site Setup On The Upper Field
Site Setup On The Upper Field

Site setup at Hollis-Brookline High School began with the 40M V-Beam.

Field Day 2017 Site Setup On The Upper Field - The 60 Ft Tower Coming Together
Site Setup On The Upper Field – The 60 Ft Tower Coming Together

The tower team began on the lower field by setting up the new 60 ft. tower.

Field Day 2017 - The V-Beam Was Back
The V-Beam Was Back

The 40M V-beam was awesome as ever and went up in record time…

Field Day 2017 - A New 60 Ft Tower
New 60 Ft Tower

and our new 60 ft. tower was a sight to behold!

Field Day 2017 - 40M SSB Station
40M SSB Station

We built lots of stations – 3 SSB, 3 CW, a GOTA station, a 6M Station with a new yagi, and a computer controller Satellite Station. We also setup a 2M/70cm Go Kit for talk-in and APRS demos. All totaled, we had 10 transmitters on the air! Our exchange was 7A NH.

Field Day 2017 Solar Power Setup
Solar Power Setup

We got our Solar-Battery bonus late on Saturday.

Field Day 2017 - Brian, AB1ZO Operating SSB
Brian, AB1ZO Operating SSB

Everyone operated very hard and we made more contacts than last year!

Field Day 2017 CW Ops - Dennis, K1LGQ
CW Ops – Dennis, K1LGQ

Our CW operators were amazing again this year. Here’s Dennis banging out CW QSOs. Dave, KM3T even operated SO2R for a period – calling “CQ” and working contacts on both 20M and 40M CW at the same time! Gene, W3UA brought his CW skimmer and we set up an OCF dipole to provide on-site CW spots.

Field Day 2017 - And The Generators Played On...
And The Generators Played On…

And the new generators worked flawlessly and were much easier to service.

Field Day 2017 - Curtis, N1CMD Making Satellite Fun!
Curtis, N1CMD Making Satellite Fun!

Curtis, N1CMD ran our Satellite Station 2.0 and wowed everyone while making satellite contacts….

Field Day 2017 Satellite Station 20 In Action
Satellite Station 20 In Action

and our visitors got a kick out of seeing the computer controlled satellite antennas.

Team Finchum In Action
Team Finchum In Action

Team Finchum was in high gear as always – here’s Abby, AB1BY operating with her brother Connor, KC1GGX. It seemed like Abby was on every SSB station that I looked at all weekend long…

New Digital Station For Field Day 2017
New Digital Station For 2017

Our new SDR powered Digital Station worked well and we had lots of digital contacts using the antennas on the new 60 ft. tower.

Field Day 2017 SDR GOTA Was Cool!
The SDR GOTA Was Cool!

The SDR-based GOTA station worked out super well. Ira, KC1EMJ was our GOTA coach and was busy on Saturday and Sunday introducing our guests and newly licensed members to “high-tech” Amateur Radio. We had many young people try Amateur Radio for the very first time on our GOTA station.

Field Day 2017 Remote SDR System
Remote SDR System

We operated the two SDRs for the Digital and GOTA station remotely over a coax cable data link between the upper and lower fields. Pierce, K1FOP and Dave, K1DLM put together this high-tech setup and the underpinning data networking system.

Field Day 2017 - John, W1SMN and Desmond, WK1V Operating SSB
John, W1SMN, and Desmond, WK1V Operating SSB

Did I mention that we operated hard making lots of QSOs?…

Field Day 2017 Drone Sighting
Drone Sighting

There were Drone sighting all weekend long…

and Desmond, WK1V got some amazing video from the air.

It was a lot of fun operating as N1FD, 7A NH!

Anita, AB1QB, our scoring chairman is still working on tallying up our score but it will be higher than last year.

Please take a minute and send me any photos or video that you have from Field Day 2017. We’ll be producing a video of all of the fun for the Field Day 2017 Recap at our club meeting on July 11th. Don’t miss it!

Fred, AB1OC

Hashtags: #ARRLFD #N1FD

2017 Field Day Operation

Come join us for our 2017 Field Day Operation. We will setup at the Hollis-Brookline High School on Friday and Saturday Morning. Field Day On Air Operations will commence at 2 pm local time on Saturday and run for 24 hours. There will be lots of activities for everyone to participate in. If you’d like to help with Field Day, please contact Dave, K1DLM or post in the Field Day Forum here on our website.

Go Kit for Field Day and EMCOM

We’ve been thinking about building a portable Go Kit for VHF/UHF Emergency Communications (EMCOM) and Field Day Applications for a while now. The following is a list of our requirements for a Go Kit –

  • 2m and 70cm operation with FM simplex and repeaters
  • APRS capability and tactical display for portable coordination
  • Digital messaging capability
  • Weather band monitoring capability
  • AC Power with flexible battery backup options

A plan to build our Go Kit came together during our trip to the Dayton Hamvention this year.

EMCOM Go Kit - Kenwood TM-D710GA At Dayton
Kenwood TM-D710GA At Dayton

The heart of any Go Kit is the Transceiver. We’ve been using Kenwood equipment for our APRS iGate for some time now and we have had good results with it. Kenwood’s latest 50W transceiver with APRS is the TM-D710GA. This unit provides full support for APRS tactical applications and now includes a built-in GPS receiver making it ideal for our Go Kit application.

EMCOM Go Kit - AvMap GeoSat 6 APRS Tactical Display
AvMap GeoSat 6 APRS Tactical Display

We have been using the Kenwood TM-D710 along with an AvMap GeoSat APRS display in our APRS iGate setup and the combination works very well. The AvMap display lets one see the location of portable and mobile APRS stations on a map display. This arrangement is perfect for coordinating activities in an EMCOM situation. The AvMap GeoSat 6 APRS display is no longer in production but I was able to locate a nearly new unit on eBay.

EMCOM Go Kit Packaging



EMCOM Go Kit - iPortable Enclosure
iPortable Enclosure

We had a chance to look at the iPortable enclosure at Dayton and decided that their Pro 2 4U deep unit would be a good choice for our Go Kit application. The iPortable enclosures are based on a portable rack mount case and include a DC power system, speaker and headphone hookups, a light, and provisions for a cooling fan.

EMCOM Go Kit Construction



EMCOM Go Kit - Radio Shelf
Radio Shelf

With all the components in hand, we began the construction of our Go Kit. Reliability is important in any portable system like this so we put some time into securely mounting all of the equipment and neatly arranging the cabling. First came the shelf which holds the Kenwood transceiver and a SignaLink USB sound card. A combination of drilling the shelf to secure gear with large cable ties and #8 stainless hardware was used here.

EMCOM Go Kit - Coax Connector Cables
Coax Connector Cables

Our iPortable case was equipped with both SO-239 and N-connectors on the front panel to allow for antennas and feed lines equipped for either connector type. To make the change over between the connector types easy, we installed separate PL-259 jumper cables for each connector. One simply connects the appropriate jumper to the radio.

EMCOM Go Kit - Display and Power Shelf
Display and Power Shelf

The power and AvMap display shelf were next. The AvMap display mount was dissembled and modified to accept a custom mounting bracket.

EMCOM Go Kit - PWRgate Battery Interface and Charger
PWRgate Battery Interface and Charger

The iPortable enclosure was drilled to mount a West Mountain Radio PWRgate to handle backup battery charging and management. The PWRgate supports instantaneous switching between an AC power supply and a backup battery and can accommodate a wide range of battery types and sizes.

EMCOM Go Kit Backup Battery
Backup Battery

The PWRgate was configured to properly charge our 18AH AGM backup battery. Note the use of a fuse in series with the battery for safety reasons. We used a Powerwerx SPS-30DM adjustable power supply set to 14.5Vdc to operate our Go Kit and to provide the proper charging voltage for our AGM battery.

EMCOM Go Kit Operation



EMCOM Go Kt - Diamond X-30 Antenna and Mast
Diamond X-30 Antenna and Mast

The last piece of the setup was the antenna. We wanted something that was portable, easy to set up and would provide good performance. We choose a Diamond X-30A 2m/70cm ground plane antenna and mounted it on a 12′ fiberglass push up mast. The feed line is made from 25′ of LMR-400UF coax. Several bungee cords are used to attach the mast to a fence post or other vertical structure.

EMCOM - Finished Go Kit In Use
Finished Go Kit In Use

The picture above shows the completed Go Kit in operation. We typically set one side of the Kenwood TM-D710GA to operate as an APRS transceiver and Digipeater and the other side to operate on a local repeater or simplex FM. The SignaLink sound card is used with a laptop computer running Fldigi and NBEMS for messaging applications. The iPortable case has a 13.8V lighter socket which connects to a power brick to power our laptop PC.

EMCOM Go Kit Packaged for Transport
Go Kit Packaged for Transport

The Go Kit is quite portable when closed. All of the equipment and cable connections are enclosed and protected by the case’s removable end caps. We’ve tested our Go Kit during our club’s weekly repeater net and it worked great. The first real use of our new Go Kit will be at Field Day this year. It will be located in our public information tent and will be used as a “talk-in” system.

Fred, AB1OC

2017 Field Day Prep – New Tower Test

We decided to put up a third tower as part of our 2017 Field Day operation. The new tower will support a tri-band yagi and wire antenna for use by our Digital and GOTA stations this year. Our Field Day plans call for this tower to be located on the middle-level soccer field at the Hollis-Brookline High School. To overcome terrain limitations, we decided that our new tower should be a 60 ft setup.

The project began with some mechanical design and planning for a new, heavy-duty Falling Derrick System. Mike K1WVO, Dave N1RF and I secured the necessary materials and hardware to make the new Falling Derrick System.

Tower Test - Equipment And Tools On Site
Equipment And Tools On Site

The team in the two pictures above met at our QTH this past weekend to transport all of the equipment for the new tower to the high school for a test setup.

Tower Test - Setting Up The Tilt Base
Setting Up The Tilt Base

The first step in the test was to locate the tower base in the center of our test area and ensure that it was level. Steel stakes were driven and retainers added to secure the base to the ground.

Tower Test - Building The Derrick
Building The Derrick

Next, we assembled the falling derrick and the first section of the tower to the base.

Tower Test - Assembling The Tower
Assembling The Tower

With the Derrick in place, we assembled the remaining sections of our 60 ft tower on the ground.

Tower Test - Driving Guy Anchors
Driving Guy Anchors

WIth the tower, Derrick and base together; we carefully located and drove the steel stakes for guying the tower, the derrick and for anchoring the pulleys associated with the falling derrick system. With this done, we made up and attached two levels of guys between the tower and the anchor stakes.

Tower Test - Completed Heavy Duty Derrick System Ready To Lift
Completed Heavy Duty Derrick System Ready To Lift

The tower is lifted by two wire cables which run between the derrick and the tower. We made these cables up to length during our test session. Multiple cables are used to ensure that the tower is fully supported during the lift.

Tower Test - Completed Derrick System - A View of the Tower
Completed Derrick System – A View of the Tower

Here’s another view of the tower and Derrick prior to the lift. We supported the tower on a ladder to make the initial lifting easier. The ladder will also be needed on Field Day to allow our tri-band yagi to be installed on the tower prior to standing it up.

Tower Test - Capstan Winch Used To Lift Tower
Capstan Winch Used To Lift Tower

There is a considerable amount of rope that needs to be pulled through several pulleys to lift the Tower/Derrick system. The pulleys provide mechanical advantage and slow the lift rate to a safe level. We used a heavy-duty gasoline powered capstan winch to pull the considerable length of rope required to lift our tower into the full upright position

Tower Test - Lifting The Tower
Lifting The Tower

With our crew fully briefed on the process and safety procedures, it was time to lift our tower. The picture above shows the lift in progress. Our setup ensures that no one needs to be in the tower’s fall zone during the lift.

Tower Test - The Tower Is Up!
The Tower Is Up!

Here’s a picture of the tower after it was up and fully guyed. Our new heavy-duty Derrick system worked very well and lifting the tower was completed smoothly and safely with very modest effort.

The Nashua Area Radio Club Tower Test Team
The Nashua Area Radio Club Tower Test Team

After a few pictures, we took the tower down and disassembled it. We had quite a few members turn out to help us with our new tower test. Thank you to everyone who pitched in to make our third tower project a success! We are looking forward to using it during Field Day 2017!

Notice: falling derrick tower systems can be dangerous if they are not engineered, built and used properly by a well-trained team. The tower system described here is unique and is not a standard falling derrick system. Significant steps and material choices were taken to ensure the safe use of the system described here to put up our tower Time was spent to train the team who used the Derrick system to use it correctly and safely. We do not recommend the system here to others as the engineering, materials, and training required for its safe construction and use may not be readily available.

Fred, AB1OC

Hashtags: #ARRLFD
